Features:
1. Independent design of control switch, aiming at forced return/forced landing/hover, captured image transmission interference.
2. The unique design of built-in cooling fan accelerates the cooling of the device.
3. Built-in antenna. Angle: around 15 degrees. Types: 1.5G Yagi 10dBi; 2.4G Yagi 10dBi; 5.8G Cylinder 14dBi.
4. It can be operated with one hand or two hands, and can be freely switched between three frequency bands.
5. Built-in safety certified rechargeable lithium battery, can last 1 hour.
Technical Specifications
|
Product Model |
ZK-DJ886（DJ100L) |
|
Product Name |
Handheld Drone Jammer |
|
Navigation and positioning frequencies |
1560-1620MHz |
|
Remote control and image transmission frequencies |
2400-2500MHz |
|
5720-5850MHz |
|
|
RF Power Output |
1560-1620MHz≥40dbm/10W |
|
2400-2500MHz≥40dbm/10W |
|
|
5720-5850MHz≥40dbm/5W |
|
|
Power Supply |
AC220V to DC27V |
|
Weight |
2.5Kg (excluding charger) |
|
Dimensions |
55*4*30cm |
|
Jammer Distance |
500 meters |
Note: This model uses RF components from a less reliable brand, and prolonged use may result in heating issues. It is a low-end, all-plastic version, suitable only for farmers, livestock breeders, and personal use.
